1927 Royal 10 Serial # X-1068512 1927 Royal 10 typewriter, Serial # X-1068512 James Grooms's 1927 Royal 10 typewriter. 2025-02-27 From the Virtual Typewriter Collection of James Grooms: 1927 Royal 10 Serial # X-1068512 A nice X series,. The paper table and hardware are bent. The platen is split in two. A KMG swap?
--------------------------------------------------------------------------------------------------------
The paper table hardware proved to be troublesome to get realigned so it would work. The platen is from a KMG, note the thickness, with a KMM right side end cap. The KMG uses a different rod and variable release so those parts will not work and the end piece has a different set screw centering. Once that's all sorted, the variable rod is too short to engage the slightly different release tab on a KMG. A 440 rod end cut to about 3mm, drops right into the cut out in the platen rod and stays in place, This provides the extra length the original 10 variable release rod needs to push in the release.

When it was dropped to bend the table hardware, is probably when the rear feet mounts were mashed. The plated feet hardware used here, I think, came from a KMM.

The slugs are "PG". So I assume this is Pica Gothic. But they are not double because the upper case letters are periods . Numerals are standard. The question mark is actually 3/4 and there is no question mark slug. What this typewriter was used for who knows, but it was used because the spacebar is concave for the right hand thumb action.

Note the side by side of this carriage shifter vs the segment shift. The cushioned feet make for a much higher stance. This S has a tab tower, which accounts for some of the weight, but not all of the six pounds.

1927 Royal 10 #X-1068512

Status: My Collection
Hunter: James Grooms (jgrooms)
Created: 11-18-2024 at 09:42AM
Last Edit: 02-27-2025 at 03:08PM

Description Hunter 27 Photos 0 Likes  Find on Ebay #AD  Find on Etsy #AD

Description:

A nice X series,. The paper table and hardware are bent. The platen is split in two. A KMG swap?
--------------------------------------------------------------------------------------------------------
The paper table hardware proved to be troublesome to get realigned so it would work. The platen is from a KMG, note the thickness, with a KMM right side end cap. The KMG uses a different rod and variable release so those parts will not work and the end piece has a different set screw centering. Once that's all sorted, the variable rod is too short to engage the slightly different release tab on a KMG. A 440 rod end cut to about 3mm, drops right into the cut out in the platen rod and stays in place, This provides the extra length the original 10 variable release rod needs to push in the release.

When it was dropped to bend the table hardware, is probably when the rear feet mounts were mashed. The plated feet hardware used here, I think, came from a KMM.

The slugs are "PG". So I assume this is Pica Gothic. But they are not double because the upper case letters are periods . Numerals are standard. The question mark is actually 3/4 and there is no question mark slug. What this typewriter was used for who knows, but it was used because the spacebar is concave for the right hand thumb action.

Note the side by side of this carriage shifter vs the segment shift. The cushioned feet make for a much higher stance. This S has a tab tower, which accounts for some of the weight, but not all of the six pounds.
